Structural Weight 150 kg
Bike Weight and Rider Weight 115 kg
Sizes SizeSplit
frame Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount
size Size Split: 27.5: XS (14"), S (16") // 29: M (18"), L (20"), XL (22"), XXL (24")
Suspension fork RockShox Judy Silver TK Coil, 100mm, Lockout
brake system Shimano BR-MT200/UR300, Hydr, Disc Brake, PM/FM (180/160)
rear derailleur Sram SX Eagle™, 12-Speed
shifters Sram SX Eagle™ Trigger
bottom bracket Sram Power Spline, 73mm BSA
crankset Sram SX Eagle™ Powerspline, 32T, 175mm
cassette Sram PG-1210 Eagle™, 11-50T
chain Sram SX Eagle™
front hub Shimano HB-TX505, QR, Centerlock
rear hub Shimano FH-TX505, QR, Centerlock
rims CUBE ZX20, 32H, Disc
tyres Schwalbe Smart Sam, Active, 2.25
handlebar CUBE Rise Trail Bar, 680mm
Stem CUBE Performance Stem SLX, 31.8mm
grips ACID React
seat post CUBE Performance Post, 27.2mm
seat clamp CUBE Varioclose, 31.8mm
saddle Natural Fit Venec Lite
headset CUBE FPH868, Semi-Integrated
pedals ACID PP MTB
weight 13,9 kg
colour flashgrey´n´red
